UNIFI
|
|
Dimensions |
160 x 160 x 31.45 mm (6.30 x 6.30 x 1.24") |
Weight |
170 g (6.0 oz), 185 g (6.5 oz) with Mounting Kits |
Networking Interface |
(1) 10/100/1000 Ethernet Port |
Ports |
No |
Buttons |
Reset |
Antennas |
(2) Dual-Band Antennas, 3 dBi Each |
Wi-Fi Standards |
802.11 a/b/g/n/ac |
Power Method |
Passive Power over Ethernet (24V), (Pairs 4, 5+; 7, 8 Return) |
Power Supply |
24V, 0.5A Gigabit PoE Adapter |
Maximum Power Consumption |
6.5W |
Max TX Power |
20 dBm |
BSSID |
Up to Four per Radio |
Power Save |
Supported |
Wireless Security |
WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) |
Certifications |
CE, FCC, IC |
Mounting |
Wall/Ceiling (Kits Included) |
Operating Temperature |
-10 to 70° C (14 to 158° F) |
Operating Humidity |
5 to 95% Noncondensing |
ADVANCED TRAFFIC MANAGEMENT |
|
VLAN |
802.1Q |
Advanced QoS |
Per-User Rate Limiting |
Guest Traffic Isolation |
Supported |
WMM |
Voice, Video, Best Effort, and Background |
Concurrent Clients |
200+ |
SUPPORTED DATA RATES (MBPS) |
|
802.11a |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11n |
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) |
802.11ac |
6.5 Mbps to 867 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80) |
802.11b |
1, 2, 5.5, 11 Mbps |
802.11g |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
